SPECYFIKACJA
Frame:CONWAY Intube Bosch, Alu
Dropout:0281175/0
Fork:RST „Vibe”, 90 mm
Headset:ZS44 / ZS56
Crank arm:FSA „CK-745”, 170 mm
Chain ring / belt ring:SRAM „Gen4 Eagle DM non-B”, 38 Z., w CG
Bottom Bracket:BOSCH
Brakes:TEKTRO „HD-M535”, 4-Kolben
Brake lever:TEKTRO „HD-M535”
Front rotor:TEKTRO „TR203-17 2,3”, 203 mm
Rear rotor:TEKTRO „TR180-17 2,3”, 180 mm
Shifting lever:SRAM „SX Eagle Trigger”, single click
Rear derailleur:SRAM „NX Eagle”, 12speed
Cassette / belt sprocket:SRAM „PG 1230 Eagle”, 11-50 Z.
Chain / belt:SRAM „SX Eagle”
Drive unit:BOSCH Mittelmotor Gen.4 „Performance CX”, 36 V, 250 W
Battery:BOSCH „Powertube 625”, Lithium-Ionen mit BMS, 625 Wh
Charger:Bosch 4 Ah
Display:BOSCH, „Kiox ” 4-Stufen, Remote Control, Schiebehilfe
Sensor:Tretkraftmessung im Motor + Geschwindigkeitssensor
Rims:RODI „Ready 30”
Spokes:Niro
Front hub:FORMULA „DC 511”, 15 x 110 mm
Rear hub:FORMULA „DC 22LW”, QR
Front tires:CONTINENTAL „eRuban Plus”, 58-584, Reflex
Rear tires:CONTINENTAL „eRuban Plus”, 58-584, Reflex
Handle bar:LEVEL 9 „Low Riser”, Ø 31,8, 720 mm
Stem:LEVEL 9 „Adjustable”, 90 mm
Grips:CONWAY „Sport fix”
Saddle:SELLE ROYAL „Vivo Athletic Ergo”, Da
Seat post:CONTEC „Drop – A – Gogo”, 31,6 mm, 100 mm
Mud Guards:SKS „A65R”, Kunststoff
Carrier:ATRAN „Cummute Pro”, inkl. Federklappe
Front light:CONTEC „DLUX 50 E+”
Tail light:CONTEC „CTL 335 E”, Stoplight
Kickstand:URSUS „Wave”, 40mm
Pedals:VP „VPE-506″
Technical data
Category:SUV
E-bike:yes
Bosch Smart System:no
Drive system:BOSCH Performance Line CX
Drive version:middle motor
Battery capacity:625 Wh
Support:till 25km/h
Sex:ladies
Frame shape:wave
Frame size:S
Frame height:42 cm
Wheel size:27,5”
Shifting type:derailleur
Gears:12-speed
Transmission:1x 12-fach
Circuit brand:SRAM
Shifting model:NX
Brake system:hydraulic disc brake
Travel:90 mm
Features:suspension fork, electronic sliding aid, fender
Zulässiges Systemgewicht:130 kg
Material:aluminium
Type:Article
Colour:gold
Colour designation:black metallic / gold matt
